1 Summary

1.1 Model Description

DCP: Represents a DC fast charger; this series of chargers are integrated dual-gun DC chargers.
D020/030/040: Denotes the rated output power of the charger.

1.2 Product Overview

The DCP-D020/030/040Z series electric vehicle DC charger provides national standard compliant charging interfaces and secure, reliable charging services. It offers an excellent user experience, supports precise metering and billing, charging record storage, payment processing functions, and has a certain level of configurability for ease of debugging.
The product mainly consists of six functional units: AC distribution unit, power conversion unit, DC output unit, charging interface, charging control unit, and user terminal.

Operating Environment

Ambient Temperature: Normal operating temperature range -25℃ to +55℃, storage temperature -30℃ to +70℃;
Altitude ≤2000 m;
Relative Humidity: 5% to 95%, without condensation;
Installation Position: Vertical installation with a maximum tilt angle not exceeding 5°;
The use location should have facilities to protect against wind, sand, rain, and snow; no corrosive gases; and must be in an environment without explosive gases;
There should be no strong vibrations or shocks at the use location.

1.3 Performance Parameters

Table 1-1 Performance parameters of the DCP-D020/030/040Z electric vehicle DC fast charger.

Project		Technical indicators
Product model specifications		DCP-D020/030/040Z
Input characteristics	Input Voltage	AC380V(1±15%) Three-phase five-wire
	AC frequency	50±1Hz
	Power Factor	≥ 0.98
	Current harmonic distortion	THDi ≤ 5%
	Full load efficiency	≥ 96％
Output characterlstics	Rated output power	20/30/40kW
	Output voltage range	DC200-1000V
	Output current range	Single circuit: O-125A
	Current limiting adjustment range	20%~100% Rating
	Voltage stabilization accuracy	≤ ±0.5%
	Steady flow accuracy	≤ ±1%(Current range 20%-100% load)
	Ripple factor	Effective value coefficient:≤ 0.5%
Protection features	Input over-voltage protection	When the input voltage is higher than the over-voltage protection setting value, the charger can automatically protect
	Input under-voltage protection	When the input voltage is lower than the under-voltage protection setting value, the charger can automatically protect
	Output over-voltage protection	When the output voltage exceeds the over-voltage setting value, the charger can automatically protect
	Output short circuit protection	When the output is short-circuited, the charger can automatically protect itself and automatically recover when the fault point is removed.
	Over temperature protection	When the internal temperature of the charger exceeds theover-temperature setting value, the charger can automatically protect
	Communication protection	Shutdown of electric vehicle communication failure
Human Machine Interface	Status indicator	Displays standby, charging and fault status
	Human machine operation unit	Equipped with 4.3-inch LCD touch screen: display charging information, battery information, human-machine operation interface
Others	Vehicle Auxiliary Power Supply Specifications	DC 12V/10A
	Operating ambient temperature	-25℃ - +55℃
	Cooling method	Forced air cooling
	Acoustic noise	≤80dB
	Protection level	IP54
	Size (mm)	20/30/40kW:690(Height)*492(Width)*183.5 (Depth)(Wall-mounted) 1568(Height)*492(Width)*263.5 (Depth)(Column-mounted)

2 Functional Features

2.1 Basic Functions

Supports multiple battery types including lithium-ion, nickel-metal hydride, and lead-acid batteries, compatible with common electric vehicle models.
Intuitive full touchscreen HMI with clear status indication for easy operation and real-time working status monitoring.
Integrates multiple intelligent modules: authentication, metering & billing, background communication, and EV communication.

2.2 Safety Protection Functions

Built-in emergency stop switch for immediate power cutoff in critical situations.
Real-time communication with the vehicle BMS to monitor traction battery status, providing reliable protection against overcharge, over-temperature, and reverse polarity.
Clear visual and text prompts to effectively prevent operator misoperation.
Interlock safety mechanism: charging starts only after a valid connection is confirmed. If an abnormal connection is detected, the charger stops charging, disconnects the DC output, and unlocks the electronic lock to ensure safe separation between vehicle and charger.

2.3 Metering & Billing Functions

Supports time-of-use billing with automatic internal calculation for fee settlement.
Provides flexible payment methods including charging cards and QR code scanning. Charging card functions are restricted to management and maintenance personnel for equipment operation and temporary startup.

2.4 Communication Functions

Real-time communication with vehicle BMS to verify connection status and obtain charging parameters and real-time operation data.
Two-way communication with upper-level monitoring platforms to upload energy, billing, and IC card information, and support remote control and management.

2.5 Historical Data Recording

Power-off data retention function prevents charging data loss during unexpected power outages.
Automatically records recent events:
Alarm events (name and start time)
Parameter setting changes and charging records (name and start time)
